GEM EB300 – Surface Mount Electric Drop Bolt with Status Output

Full Description

Surface Mount Electric Drop Bolt with Status Output

The GEM EB300 is a high-performance fail-safe electric drop bolt, designed for secure access control on double action doors or single inswing/outswing doors. Its surface mount design makes it suitable for frameless glass, hollow metal, and wooden door applications, providing a versatile and reliable alternative to electromagnetic locks or electric strikes.

Engineered with vandal resistance, the EB300 drop bolt cannot be defeated by inserting metal objects between the lock and strike plate, ensuring enhanced security. Additionally, it features built-in status sensors, including a bolt status sensor and a door position sensor, enabling seamless integration with access control and monitoring systems.

The adjustable relock time delay allows for customised locking behaviour, enhancing flexibility in high-security environments. With its fail-safe (power-to-lock) operation, the GEM EB300 ensures safe egress in case of power failure, making it an ideal solution for offices, commercial buildings, and high-traffic security doors.

Technical Specifications:

• Voltage: 12V DC
• Current Draw:
  • Pull-in: 0.9A @ 12V DC
  • Holding: 0.3A @ 12V DC
• Operation: Fail-Safe (Power to Lock)
• Installation: Surface Mount
• Security Features:
  • Bolt Status Sensor
  • Door Position Sensor
  • Vandal-Resistant Design
• See Data Sheet

Why Choose the GEM EB300 Electric Drop Bolt?

The GEM EB300 is the perfect security solution for locations where traditional electromagnetic locks or electric strikes are impractical. Its surface mount design, built-in status sensors, and fail-safe operation make it a versatile and highly secure access control option.
