CQR CABS8/WH/LSF/100 – 100m High-Performance 8 Core Screened LSF Cable (White)
The CABS8/WH/LSF/100 is a premium-grade 8 core screened Low Smoke and Fume (LSF) cable from CQR, designed to set industry standards for intruder alarm installations. This cable provides exceptional performance, low resistance, and ease of installation, making it ideal for demanding security applications.
Key Features:
- 8 Cores: CABS8/WH/LSF/100 Provides ample conductors for complex security systems.
- Screened Design: Minimises interference and ensures reliable signal transmission.
- LSF Sheathing: Low Smoke and Fume sheathing for enhanced safety in case of fire.
- Tinned Copper Conductors: Offers excellent conductivity and corrosion resistance.
- 100 Meter Spool: Provides ample cable for large installations.
- Type 2 Compliance: Meets industry standards for intruder alarm cables.
- Multi-Strand Cores: Offers flexibility and durability during installation.
- Color-Coded Insulation: Simplifies wiring and identification.
Full Description
Premium Quality LSF Cable for Professional Installations
The CQR CABS8/WH/LSF/100 is a high-quality 8 core screened cable designed for use in professional intruder alarm systems. This cable is engineered to meet industry benchmarks, offering low resistance, high core strength, and ease of installation. It features Low Smoke and Fume (LSF) sheathing for enhanced safety in sensitive environments.
Key Features of CABS8/WH/LSF/100:
- 8 Cores: CABS8/WH/LSF/100 Provides ample wiring for complex alarm systems.
- Screened Cable: Minimises interference and ensures signal integrity.
- LSF Sheathing: Low Smoke and Fume sheathing for improved safety in fire situations.
- Tinned Copper Conductors: Offers excellent conductivity and corrosion resistance.
- 100 Meter Spool: Provides ample cable for large installations.
- BS4737 Type 2 Compliance: Meets industry standards for intruder alarm cabling.
- Multi-Strand Cores: Offers flexibility and durability.
Technical Specifications:
- Number of Cores: 8
- Conductor Type: Tinned Copper
- Conductor Size: 0.182 mm² (25 AWG)
- Strands per Core: 7
- Sheathing Material: LSF (Low Smoke and Fume)
- Sheathing Colour: White
- Screen Material: Polyester / Ali foil
- Drain Wire Material: Tinned Copper
- Insulation Material: PVC
- Insulation Colours: Red, Black, Yellow, Blue, White, Green, Orange, Brown
- Length: 100 Meters
- Nominal Diameter: 4.5mm
- Max Voltage: 50V
- Max Current: 1A
- Resistance: 94.6 Ω/km
- Operating Temperature: -10°C to +70°C
- Installation Temperature: +5°C to +40°C
- EURO Class: Eca
- Weight: 3.495 kg
- Reel Size: Card 7.5″ Professional Flange / Tin 3″ x 4″
- See Data Sheet
Benefits:
- Reliable Performance: Low resistance and high core strength ensure consistent performance.
- Enhanced Safety: LSF sheathing reduces smoke and fume emissions in fire situations.
- Easy Installation: Flexible multi-strand cores and convenient 100-meter spool.
- Reduced Interference: Screened cable minimizes signal interference.
- Durable Construction: Tinned copper conductors and robust sheathing.
- Industry Compliance: Meets BS4737 Type 2 standards.
Ideal Applications:
- Intruder alarm systems
- Security systems
- Access control systems
- Other low-voltage signalling applications
Product Specifications
| Brand | CQR |
|---|---|
| Euro Class | Eca |
| Number of Cores | 8 |
| Sheathing | LSF |
| Screened | Yes |
| Cable Length | 100m |
| Cable Type | Shielded |
| SKU | CQR-CABS8/WH/LSF/100 |
